Moticam Pro S5 Lite

Tillverkare: MOTICEUROPE, S.L. / S.L.U.

Artikelnr: 726.1100600101101

Lagerstatus: Beställningsvara

Kontakta oss för pris

Antal:

i h

Overview
Kontakta oss

Moticam Pro S5 Lite

Low Light, Fast Phenomena - Moticam Pro S5 Lite delivers a 5MP mid-size resolution for all biological/medical fields, showing a premium sensitivity for lowlight situations in Fluorescence and Polarization. The Global shutter data readout helps to accelerate data transfer from fast phenomena, from single-cell organisms to industrial work with clockworks or extrusion processes.

Model	Moticam Pro S5 Lite
Sensor type	sCMOS
Sensor size	2/3"
Imaging area	11.1mm (Diagonal)
Capture resolution info	5MP
Live display mode through USB	2448x2048, 1224x1024 pixels
Pixel size	3.45x3.45μm
Scan mode	Progressive
Shutter mode	Global shutter
Data transfer	USB 3.1
Max. frames per second (fps)	2448x2048 @ 37.5fps 1224x1024 @ 88.4fps (*)
Exposure time	14 μsec to 2 sec
Operating temperature	From -10 to +60 Degrees Celsius non condensing
Max. signal to noise ratio	0.1mV @1/30 sec
Sensitivity	1146mV(G) @ 1/30 sec
Support device	TWAIN, SDK and DirectShow Driver
Minimum computer requirements	2GHz dualcore - RAM memory 2GB - Video memory min. 512 MB
Lens mount	C-Mount
Software	Motic Images Plus 3.0 for Windows 10, MAC OSX10.9, Linux UBUNTU1604 or higher
Functions	Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system.
Power supply	5V (From USB Port)
Package includes	CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0
Other features	(*) Frames per second under optimal lighting conditions and in compliance with computer technical requirements.
